◆ The multi-link drive can have either six links or eight links.
◆ The multi-link system is created using specialized software.
◆ The larger and most important components are enhanced using Finite Element Method (FEM) analysis.
◆ The asynchronous drive minimizes lateral force during sliding.
◆ The high-speed drive utilizes a herringbone gear.
◆ The slide is guided by an eight-sided rectangular guide.
◆ The part has a pneumatic friction clutch brake for partial rotation, with the option of an imported wet type clutch brake.
◆ There is a hydraulic overload protector.
◆ The main lubrication is done automatically with oil, and there is the option for a heating and cooling system.
◆ The machine has dual control: electronic cam and mechanical cam.
◆ Optional features include an air cushion and a quick die change device.
