◆ The main focus of the FEM optimization process is to enhance the larger and more significant components.
◆ The welded crown, column, and bed are fastened using tie rod bolts, ensuring strong intensity and rigidity when subjected to pressure.
◆ The asynchronous drive minimizes the sideways force on the small slide.
◆ The drive gear is constructed from a high-strength alloy steel, while the herringbone gear in the high-speed gear pair and the straight gear in the low-speed gear pair are hardened and ground for long-lasting durability.
◆ The slide is guided by an eight-sided rectangular guide.
◆ The machine is equipped with a pneumatic friction clutch brake that operates partially, and there is also the option of an imported wet type clutch brake.
◆ A hydraulic overload protector with high sensitivity is included.
◆ Automatic oil lubrication is provided to ensure smooth operation.
◆ The machine is fitted with an imported safety dual solenoid valve.
◆ There are two control alternatives: electronic cam and mechanical cam.
◆ Additional features that can be added include an air cushion, moving bolster (JD36-400/500), tonnage gauge, and anti-vibration pads.
