◆ FEM optimizes the larger and primary components.
◆ The welded crown, column, and bed are pre-tensioned using tie rod bolts, resulting in high intensity and rigidity when pressed.
◆ The asynchronous drive minimizes lateral forces on the small slide.
◆ The drive gear is made of high strength alloy steel, while the high-speed gear pair features a herringbone gear. The low-speed gear pair is made of tooth-grinded hardened straight gear.
◆ The slide features an eight-sided rectangular guide.
◆ The machine is equipped with a pneumatic friction clutch brake for partial revolution, with the option to upgrade to an imported wet type clutch brake.
◆ A hydraulic overload protector with high sensitivity is included.
◆ Automatic oil lubrication ensures smooth operation.
◆ The machine is equipped with an imported safety dual solenoid valve.
◆ Double control is provided through both electrical and mechanical cams.
◆ Optional features include an air cushion, tonnage gauge, and anti-vibration pads.
