◆ The spm is up to 50-100 times/min, with high working speed, short contact time between the mold and the workpiece, low temperature rise and high life of the mold.
◆ Flywheel rotation inertia, high output energy, especially suitable for all kinds of parts of hot forging and extrusion technology. HGP machine tool adopts two-stage transmission structure, adding a set of gears to drive, and the output energy is higher than HFP machine.
◆ The fuselage is welded composite fuselage, and adopts high strength pull rod hydraulic pre-tightening, easy to disassemble and transport, good overall stiff ness, high forging precision.
The width of HGP machine table improves the adapt ability of user’s production process.
◆ Wide-body two-point integral connecting rod and extended guide rail design,strong anti-deviant load capacity, can be set in multiple station.
◆ With side window, transverse feeding, combined with the stepping manipulatorto achieve multi-station automatic forging, forging automation degree is high.
◆ "X" type guide design can effectively make up for the change of guide clear ance caused by temperature rise.
◆ The closed height is adjusted by the eccentric pin inside the slider to be stable and reliable.
◆ Clutch and brake with floating insert friction block design, simple and reliable structure, easy maintenance; And adopt tooth guide, brake, clutch operation precision is high, brake and clutch noise is small, friction block life is higer;Brake with forced cooling system, brake temperature rise is small, can achievehigh speed single operation.
◆ The control system integrates air pressure monitoring, shaft temperature monitoring, cooling water monitoring, lubrication monitoring, fault display, eccentric shaft speed and Angle monitoring, etc., with high degree of automation.
◆ Equipped with touch screen, the parameters can be adjusted flexibly.
◆ The spm is up to 50-100 times/min, with high working speed, short contact time between the mold and the workpiece, low temperature rise and high life of the mold.
◆ Flywheel rotation inertia, high output energy, especially suitable for all kinds of parts of hot forging and extrusion technology. HGP machine tool adopts two-stage transmission structure, adding a set of gears to drive, and the output energy is higher than HFP machine.
◆ The fuselage is welded composite fuselage, and adopts high strength pull rod hydraulic pre-tightening, easy to disassemble and transport, good overall stiff ness, high forging precision.
The width of HGP machine table improves the adapt ability of user’s production process.
◆ Wide-body two-point integral connecting rod and extended guide rail design,strong anti-deviant load capacity, can be set in multiple station.
◆ With side window, transverse feeding, combined with the stepping manipulatorto achieve multi-station automatic forging, forging automation degree is high.
◆ "X" type guide design can effectively make up for the change of guide clear ance caused by temperature rise.
◆ The closed height is adjusted by the eccentric pin inside the slider to be stable and reliable.
◆ Clutch and brake with floating insert friction block design, simple and reliable structure, easy maintenance; And adopt tooth guide, brake, clutch operation precision is high, brake and clutch noise is small, friction block life is higer;Brake with forced cooling system, brake temperature rise is small, can achievehigh speed single operation.
◆ The control system integrates air pressure monitoring, shaft temperature monitoring, cooling water monitoring, lubrication monitoring, fault display, eccentric shaft speed and Angle monitoring, etc., with high degree of automation.
◆ Equipped with touch screen, the parameters can be adjusted flexibly.
