◆ Entire steel welded frame with carbon dioxide arc weld- ing; stress relieved after welding and machining; entire tempering and blasting with high rigidity .
◆ Specific eccentric shaft structure with short pivot distance and high rigidity.
◆ Steel welded slide operated within frame guide; eight- face high intensity frame with high guide accuracy and high strong eccentric load resistance capacity; avail- able for multi-station forging.
◆ Imported hydraulic overload protector is adopted inside slide. it is unloaded immediately, slide is stopped and- meanwhile electrical signal is sent if press is overload- ed to protect press and dies.
◆ Separated dry type pneumatic friction clutch brake with big transmitted torque and large output; easy for installa- tion and maintenance.
◆ E1P-xxxS type press with three-stage drive customized for specific process demand.
◆ Entire steel welded frame with carbon dioxide arc weld- ing; stress relieved after welding and machining; entire tempering and blasting with high rigidity .
◆ Specific eccentric shaft structure with short pivot distance and high rigidity.
◆ Steel welded slide operated within frame guide; eight- face high intensity frame with high guide accuracy and high strong eccentric load resistance capacity; avail- able for multi-station forging.
◆ Imported hydraulic overload protector is adopted inside slide. it is unloaded immediately, slide is stopped and- meanwhile electrical signal is sent if press is overload- ed to protect press and dies.
◆ Separated dry type pneumatic friction clutch brake with big transmitted torque and large output; easy for installa- tion and maintenance.
◆ E1P-xxxS type press with three-stage drive customized for specific process demand.
